| Size |
Overall Length / mm |
Thread Length / mm |
| M3 x 0.35 |
40 |
9 |
| M4 x 0.36 |
45 |
10 |
| M4 x 0.5 |
45 |
10 |
| M5 x 0.5 |
50 |
12 |
| M6 x 0.5 |
50 |
14 |
| M6 x 0.75 |
50 |
14 |
| M7 x 0.75 |
50 |
14 |
| M8 x 0.5 |
50 |
19 |
| M8 x 0.75 |
50 |
19 |
| M8 x 1 |
56 |
22 |
| M9 x 1 |
63 |
22 |
| M10 x 0.75 |
63 |
20 |
| M10 x 1 |
63 |
20 |
| M10 x 1.25 |
70 |
24 |
| M10 x 0.78 |
63 |
20 |
| M11 x 1 |
70 |
22 |
| M12 x 1 |
70 |
22 |
| M12 x 1.25 |
70 |
22 |
| M12 x 1.5 |
70 |
22 |
| M13 x 1 |
70 |
22 |
| M13 x 1.5 |
70 |
22 |
| M14 x 1 |
70 |
22 |
| M14 x 1.25 |
70 |
22 |
| M14 x 1.5 |
70 |
22 |
| M15 x 1 |
70 |
22 |
| M15 x 1.5 |
70 |
22 |
| M16 x 1 |
70 |
22 |
| M16 x 1.25 |
70 |
22 |
| M16 x 1.5 |
70 |
22 |
| M18 x 1 |
80 |
22 |
| M18 x 1.25 |
80 |
22 |
| M18 x 1.5 |
80 |
22 |
| M18 x 2 |
80 |
22 |
| M20 x 1 |
80 |
22 |
| M20 x 1.25 |
80 |
22 |
| M20 x 1.5 |
80 |
22 |
| M20 x 2 |
80 |
22 |
| M22 x 1 |
80 |
22 |
| M22 x 1.5 |
80 |
22 |
| M22 x 2 |
80 |
22 |
| M24 x 1 |
90 |
22 |
| M24 x 1.5 |
90 |
22 |
| M24 x 2 |
90 |
22 |
|
| Size |
Overall Length / mm |
Thread Length / mm |
| M25 x 1.5 |
90 |
22 |
| M26 x 1.5 |
90 |
22 |
| M26 x 2 |
90 |
22 |
| M27 x 1.5 |
90 |
22 |
| M27 x 2 |
90 |
22 |
| M28 x 1.5 |
90 |
22 |
| M28 x 2 |
90 |
22 |
| M30 x 1 |
90 |
22 |
| M30 x 1.5 |
90 |
22 |
| M30 x 2 |
90 |
22 |
| M32 x 1.5 |
90 |
22 |
| M33 x 1.5 |
100 |
25 |
| M33 x 2 |
100 |
25 |
| M34 x 1.5 |
100 |
25 |
| M35 x 1.5 |
100 |
25 |
| M36 x 1.5 |
100 |
25 |
| M36 x 2 |
125 |
40 |
| M36 x 3 |
125 |
40 |
| M38 x 1.5 |
100 |
25 |
| M39 x 2 |
125 |
40 |
| M39 x 3 |
125 |
40 |
| M40 x 1.5 |
110 |
25 |
| M40 x 2 |
125 |
40 |
| M42 x 1.5 |
110 |
25 |
| M42 x 2 |
125 |
40 |
| M42 x 3 |
125 |
40 |
| M45 x 1.5 |
110 |
25 |
| M45 x 2 |
125 |
40 |
| M45 x 3 |
125 |
40 |
| M48 x 1.5 |
140 |
40 |
| M48 x 2 |
140 |
40 |
| M48 x 3 |
140 |
40 |
| M50 x 1.5 |
140 |
40 |
| M52 x 1.5 |
140 |
40 |
| M52 x 2 |
140 |
40 |
| M52 x 3 |
140 |
40 |
|
